Ford Econoline Porthole Window 12″ Round (1992+)

Ford Econoline Porthole Window 12″ Round (1992+)

Ford Econoline porthole windows are a fantastic upgrade for Ford Econoline art van replacement windows.

Product Description

Elevate the appearance of your Ford Econoline van with the VWD Van Porthole Window 12″ Round (PORT12). Boasting a timeless design, this window adds a touch of classic charm to any van conversion or cargo setup. Installation is effortless thanks to the reversible clamp ring, available in 1/8″ (3.2 mm) or 1-1/2″ (38.1 mm) sizes. The black powder-coated aluminum frame not only enhances the window’s aesthetic appeal but also ensures durability against diverse weather conditions.

Featuring a 3M UV-coated foam seal, the VWD Van Porthole Window guarantees a watertight and secure fit. With an outside diameter of 12-7/8″ and a cut hole diameter of 11-11/16″, this window is perfectly sized for your Ford Econoline van. Crafted from high-quality materials, including DOT/SAE-approved glass with 17% UV filtration, it provides excellent protection against harmful UV rays while offering a level of privacy.

Manufactured in China, the VWD Van Porthole Window comes with a 1-year warranty, ensuring long-lasting performance and providing peace of mind to van owners. With its classic appearance, easy installation, and reliable construction, this window is an essential addition for those looking to enhance both the style and functionality of their Ford Econoline vans.

Product Details

• Black Powder Coated Aluminum Frame 1/8″ (3.2 mm) or 1-1/2″ (38.1 mm)

• Black Reversible Clamp Ring

• 3M UV Coated Foam Seal Included

• Classic Look

• Outside Diameter: 12-7/8″

• Cut Hole Diameter: 11-11/16″

• Mfg Country = China

• Mfg Warranty = 1 Year

Tips for an easy install on your Ford Econoline replacement windows:

• If possible, cut the openings with a center-blade shear rather than a jigsaw. This produces a cleaner opening, reduces debris, and minimizes hammering on the sheet metal of the van.

• Make sure to paint the cut edges of the new window opening. Skipping this step can cause rust on the edges of the window mounting.

• These windows are designed to clamp onto the sheet metal body of the vehicle and do not require any spacers. They cannot clamp to anything larger than 1/8″.

• Let the self-tapping screws bore their own hole, but pre-drill with a 1/16″ metal drill bit to help get them started without risking damage to the window or screw. For faster installation, use a drill to get the screw started, then finish tightening with a handheld screwdriver to avoid stripping the hole.

Universal art van replacement windows
